Product
SF Fixed-Angle Rotary Nozzles
Set-and-forget rotary streams for standard zones – same footprint as a spray nozzle, one third the precipitation rate.
Request a Quote
Specifications (per product catalog)
| Model | Radius | Arcs | Example flow (m³/h) |
|---|---|---|---|
| SF12-90/180/270/360 | 3 m | 90° 180° 270° 360° | 0.019 (90°) … 0.039 (360°) @2 bar |
| SF18-90/180/270/360 | 5 m | 90° 180° 270° 360° | 0.035 (90°) … 0.125 (360°) @3 bar |
| SF24-90/180/270/360 | 7 m | 90° 180° 270° 360° | 0.038 (90°) … 0.168 (360°) @3 bar |
Uniform zones
All SF nozzles share rated flows, so one zone mixes arcs freely.
Wind-resistant
Multi-stream pattern resists drift better than a solid spray cone.
Same-thread fit
Threads into 1/2″ pop-up bodies – RW or most standard brands.
Low flow, more zones
Lower precipitation lets one valve feed more heads.
Frequently asked questions
Can SF and N nozzles share a zone?
Yes – they are flow-matched by design, per catalog.
Which SF for a 6 m square lawn?
SF24 (7 m) on 90° corners and 360° centers gives head-to-head overlap on a 6 m grid.
