PR20 Pressure Regulator
Pressure swings ruin uniformity. The PR20 pins the downstream pressure with ±0.2 bar accuracy.
Request a Quote
Specifications (per product catalog)
| Parameter | Value (per catalog) |
|---|---|
| Max inlet pressure | ≤6.9 bar |
| Outlet setting range | 1.0-6.9 bar |
| Accuracy | ±0.2 bar |
| Adjustment | top knob, 0.02 bar steps with 0.2 bar click |
| Fits valves | RWV 3/4″, 1″, 1¼”, 1½”, 2″ |
| Install | under the valve, inline or angle; also fits above-ground setups |
| Inlet requirement | inlet pressure must exceed outlet by ≥1.0 bar |
| Min flow caution | below 0.27 m³/h, screw the knob two turns down |
| Max rated pressure | 13.8 bar body; sustained 6.9 bar downstream |
Readable scale
The transparent body shows the setting – set pressure without gauges.
Water-stop install
Disengage the plug and the valve can be serviced without draining the line.
Dust-proof cap
The adjuster is protected against grit and moisture.
Anti-tamper option
The cap locks the setting on public sites.
Frequently asked questions
Where should the regulator be installed?
Directly below the solenoid valve (or inline upstream of nozzles). The catalog notes inlet must be ≥1.0 bar above the target outlet pressure.
Does the PR20 reduce pressure at zero flow?
It regulates while flowing; check static performance in the catalog pressure tables for your setting.
Market terms (live harvest, Bing, Sep 2026):
EN: irrigation pressure regulator, sprinkler pressure regulator valve, inline pressure regulator drip irrigation
DE: druckregler bewässerung
FR: réducteur de pression arrosage
EN: irrigation pressure regulator, sprinkler pressure regulator valve, inline pressure regulator drip irrigation
DE: druckregler bewässerung
FR: réducteur de pression arrosage
Planning an irrigation project?
Send us your area, water source and crop or turf type – our engineers will reply with a system proposal.
