Product

CA08 8-Zone Controller

The workhorse for homes and small parks: eight independent zones, six start times each, and sensor logic.

Specifications (per product catalog)

Parameter	Value (per catalog)
Stations	8 + master valve/pump relay
Models	CA08 (AC 24 VAC coils) / CD08 (DC 9 V coils)
Schedules per zone	6 start times; weekly / odd / even / interval days
Seasonal adjustment	one-touch % budget per program
Manual control	immediate zone or full-program run
Dimensions	161 × 152 × 36 mm
Power	input 220 V AC 50 Hz; output 24 VAC 1 A (CA08) / 9 V DC 600 mA (CD08)
Expansion	optional Wi-Fi module for remote control

Six starts per zone

Multi-cycle programs for slopes and drip – shorter, repeated watering.

Zone-independent budgets

Trim each zone by % without rewriting run times.

Sensor logic

Rain and soil-moisture inputs pause the schedule automatically.

Wi-Fi ready

Add the module to run the controller from anywhere.

Frequently asked questions

AC or DC version?

CA08 drives standard 24 VAC valves in a powered valve box; CD08 drives 9 V DC latching valves where no neutral is available.

Can CA08 control a pump?

Yes – the master output can drive a pump start relay.
